进口气动罐底调

进口气动罐底调

品牌:美国威盾VTON

Brand:VTON

产品系列:调节阀

Product series:Control valve

压力范国:0-1000Mpa

Pressure range:

控制方式：电动，气动，自力式

Control method:Electric,pneumatic,self-operated

口径范围:DN1-500

Caliber range

阀体材质: 黄铜，铸铁，铸钢，不锈钢304、316等

Bodymaterial Brass, cast iron, cast steel, stainless steel 304, 316, etc

使用介质:水、油、蒸汽、燃气、空气、氢气、氮气等气体，以及各种腐蚀性流体

Using media:,Water, oil, steam, gas, air, hydrogen, nitrogen, gases, and various corrosive fluids

主要特征:调节性能稳定，精度高，使用寿命长

Main features：S adjustment performance, high precision and long service life

产品介绍

一、进口气动罐底调节阀

进口气动罐底调节阀（美国威盾VTON）Pneumatic tank bottom regulating valve，是一种特殊结构型式的单座调节阀，阀体成Y形，阀体流路流畅，流量大，压降损失小，阀座泄漏量符合ANSIBIG.104标准，该气动调节阀配用VPA多弹式薄膜执行机构，基结构紧凑；输出力大，美国威盾VTON气动罐底调节阀最适宜控制容易沉积或含有颗粒的流体。

The Pneumatic Tank Bottom Regulating Valve (VTON) is a special type of single seat regulating valve with a Y-shaped valve body. The valve body has a smooth flow path, high flow rate, low pressure loss, and the valve seat leakage meets the ANSIBIG.104 standard. The pneumatic regulating valve is equipped with a VPA multi elastic thin film actuator, with a compact base structure; The output power is high, and the American shield VTON pneumatic tank bottom control valve is most sui for controlling fluids that are prone to sedimentation or contain particles.

二、进口气动罐底调节阀技术参数和性能指标

阀体：WCB、 ZG230-450、ZG1Cr18Ni9Ti、ZG1Cr18Ni12Mo2
阀芯：0Cr18Ni12Mo2、司钛莱合金堆焊
阀座：聚四氟乙烯
阀杆、推杆：2Cr13、1Cr18Ni9Ti
膜盖：A3
弹簧：60Si2Mn
填料：聚四氟乙烯、柔性石墨、不锈钢波纹管
垫片：橡胶石棉板、1Cr18Ni9Ti、石墨缠绕垫片

三、进口气动罐底调节阀详细技术系数
