进口气动保温调节阀

进口气动小流量调节阀

品牌:美国威盾VTON

Brand:VTON

产品系列:调节阀

Product series:Control valve

压力范国:0-1000Mpa

Pressure range:

控制方式：电动，气动，自力式

Control method:Electric,pneumatic,self-operated

口径范围:DN1-500

Caliber range

阀体材质: 黄铜，铸铁，铸钢，不锈钢304、316等

Bodymaterial Brass, cast iron, cast steel, stainless steel 304, 316, etc

使用介质:水、油、蒸汽、燃气、空气、氢气、氮气等气体，以及各种腐蚀性流体

Using media:,Water, oil, steam, gas, air, hydrogen, nitrogen, gases, and various corrosive fluids

主要特征:调节性能稳定，精度高，使用寿命长

Main features：S adjustment performance, high precision and long service life

产品介绍

一、进口气动保温调节阀概述

进口气动保温调节阀（美国威盾VTON），Pneumatic insulation control valve，也叫夹套保温调节阀，由气动薄膜执行器和带夹套保温的调节阀体组成，进口气动保温调节阀适用于需要保温的场合。当工艺介质的结晶温度低于环境温度或流体温度降低，造成粘度增加或流体出现凝固时，这时在阀体和上阀盖处增设蒸汽保温夹磁装置，使工艺过程按要求进行下去。气动保温调节阀的泄漏符合ANSI B16.104标准。气动保温调节阀配用多弹簧薄膜执行机构，其结构紧凑，输出力大。

Pneumatic insulation control valve (VTON), also known as jacket insulation control valve, is composed of a pneumatic thin film actuator and a regulating valve body with jacket insulation. Imported pneumatic insulation control valves are sui for situations that require insulation. When the crystallization temperature of the process medium is lower than the ambient temperature or the fluid temperature decreases, causing an increase in viscosity or solidification of the fluid, steam insulation and magnetic clamping devices are added at the valve body and upper valve cover to ensure that the process proceeds as required. The leakage of the pneumatic insulation regulating valve complies with ANSI B16.104 standard. The pneumatic insulation regulating valve is equipped with a multi spring diaphragm actuator, which has a compact structure and a large output force.
