进口磁力驱动泵

进口磁力驱动泵

品牌:美国威盾VTON

Brand:VTON

产品系列:磁力泵

Product series:Magnetic pump

流量范围:1~120m3/h

Flow range:

压力范围:1.6Mpa

Pressure Range:

扬程范围:5-50m

Lift range:

介质温度:20C~100°C

Temperature：

泵体材质:铸铁，铸钢，不锈钢，氟塑料，衬氟

Body material:Cast iron,cast steel,stainless steel, fluoroplastic, fluorine-lined

使用介质:各类酸性、碱性、氧化性、毒性、油类介质及贵重介质

Using media:Various acidic,alkaline,oxidizing, toxic, oily and precious media

产品介绍

一、进口磁力驱动泵产品概述

V-CQ型磁力驱动泵（简称磁力泵）是将永磁联轴器的工作原理应用于离心泵的新产品，设计合理、工艺先进、具有全密封、无泄漏、耐腐蚀的特点。磁力泵以静密封取代动密封，使泵的过流部件处于完全密封状态，彻底解决了其它泵机械密封无法避免的跑、冒、滴之弊端。磁力泵选用耐腐蚀、高强度的工程塑料、刚玉陶瓷，不锈钢等作为制造材料，因此它具有良好的抗腐蚀性能，并可以使被输送介质免受污染。

The V-CQ type magnetic drive pump (referred to as magnetic pump) is a new product that applies the working principle of permanent magnet couplings to centrifugal pumps. It has a reasonable design, advanced technology, fully sealed, leak free, and corrosion-resistant characteristics. Magnetic pumps replace dynamic seals with static seals, ensuring that the overcurrent components of the pump are in a completely sealed state, completely solving the problems of running, emitting, and dripping that cannot be avoided by other pump mechanical seals. Magnetic pumps use corrosion-resistant and high-strength engineering plastics, corundum ceramics, stainless steel, and other materials as manufacturing materials, so they have good corrosion resistance and can protect the transported medium from pollution.

二、进口磁力驱动泵产品特点

磁力泵结构紧凑、外形美观、体积小、噪音低、运行可靠、使用纵方便泵体外壳用金属材料固定，故泵体足以承托管道的重量，使用保养及为方便。流量：1.8-100m3/h 　扬程：8-32m　功率：0.12－22KW 适用温度：-20~100℃
The magnetic pump has a compact structure, beautiful appearance, small size, low noise, reliable operation, and convenient use. The pump body shell is fixed with metal materials, so the pump body is sufficient to support the weight of the pipeline, and is convenient for use and maintenance. Flow rate: 1.8-100m3/h Head: 8-32m Power: 0.12-22KW Applicable temperature: -20~100 ℃

三、产品用途

不含固体颗粒腐蚀液体、强酸、强碱、乙醇、漂白剂、照相液、硝酸、盐酸、氢氟酸、醋酸、氢氧化纳、丙酮、四氧乙烷、海水、盐水等等。

Does not contain corrosive liquids such as solid particles, strong acids, strong bases, ethanol, bleaching agents, photographic fluids, nitric acid, hydrochloric acid, hydrofluoric acid, acetic acid, sodium hydroxide, acetone, ethylene oxide, seawater, saltwater, etc.
