进口自吸式磁力驱动泵

进口自吸式磁力驱动泵

品牌:美国威盾VTON

Brand:VTON

产品系列:磁力泵

Product series:Magnetic pump

流量范围:1~120m3/h

Flow range:

压力范围:1.6Mpa

Pressure Range:

扬程范围:5-50m

Lift range:

介质温度:20C~100°C

Temperature：

泵体材质:铸铁，铸钢，不锈钢，氟塑料，衬氟

Body material:Cast iron,cast steel,stainless steel, fluoroplastic, fluorine-lined

使用介质:各类酸性、碱性、氧化性、毒性、油类介质及贵重介质

Using media:Various acidic,alkaline,oxidizing, toxic, oily and precious media

产品介绍

一、进口自吸式磁力驱动泵产品概述

V-ZV-CQ型自吸式磁力驱动泵（以下简称自吸泵），该泵以静密封取代动密封，使泵的过流部件处于完全密封状态，彻底解决了其它泵机械密封无法避免的跑、冒、滴、漏之弊病，泵体及过流部件的材料均采用了耐腐蚀的不锈钢、钢玉陶瓷、四氟石墨等材料制造，既有ＣＱ型磁力驱动泵的功能，又集自吸于一身，不需底阀和引灌水，自吸高度４米。

The V-ZV-CQ self-priming magnetic drive pump (hereinafter referred to as the self-priming pump) replaces the dynamic seal with a static seal, ensuring that the overcurrent components of the pump are in a completely sealed state, completely solving the problems of running, emitting, dripping, and leaking that cannot be avoided by other pump mechanical seals. The materials of the pump body and overcurrent components are made of corrosion-resistant stainless steel, steel jade ceramics, PTFE graphite and other materials, which not only have the function of a CQ type magnetic drive pump, but also integrate self-priming without the need for a bottom valve and drainage water. The self-priming height is 4 meters.

二、进口自吸式磁力驱动泵产品特点

磁力泵结构紧凑、外形美观、体积小、噪音低、运行可靠、使用纵方便泵体外壳用金属材料固定，故泵体足以承托管道的重量，使用保养及为方便。流量：1.8-100m3/h 　扬程：8-32m　功率：0.12－22KW 适用温度：-20~100℃
The magnetic pump has a compact structure, beautiful appearance, small size, low noise, reliable operation, and convenient use. The pump body shell is fixed with metal materials, so the pump body is sufficient to support the weight of the pipeline, and is convenient for use and maintenance. Flow rate: 1.8-100m3/h Head: 8-32m Power: 0.12-22KW Applicable temperature: -20~100 ℃

三、产品用途

不含固体颗粒腐蚀液体、强酸、强碱、乙醇、漂白剂、照相液、硝酸、盐酸、氢氟酸、醋酸、氢氧化纳、丙酮、四氧乙烷、海水、盐水等等。

Does not contain corrosive liquids such as solid particles, strong acids, strong bases, ethanol, bleaching agents, photographic fluids, nitric acid, hydrochloric acid, hydrofluoric acid, acetic acid, sodium hydroxide, acetone, ethylene oxide, seawater, saltwater, etc.
